SKU: mITX-H110A Category:

mITX-H110A

Mini-ITX form factor
Supports 7/6th Generation Intel® Core™ i7/i5/i3, Pentium® and Celeron® Processors
Intel® H110 Express Chipset
Dual Channel DDR4, 2 x SO-DIMMs
2 x GbE LAN ports
3 x SATA 6Gb/s ports with a SATA DOM supported
1 x 2280/2242 M.2 M-Key Storage SATA Slot
HDMI, Display Port, VGA, LVDS/eDP ports for multiple display
2 x RS-232/422/485, 5V/12V/RI COM Ports

Core System

Part Number mITX-H110A
Size(Format) 6.7" (Mini-ITX)
CPU Intel LGA1151 socket supports 6th/7th generation 14nm Intel Kaby Lake/Skylake Core i7/i5/i3 and Celeron processors (CPU sold separately)
Chipset SoC integrated
System Memory 2x SO-DIMM DDR4 2133/24000 MHz up to 32 GB
Storage 3x SATA III + 1x M.2 SSD
Display Interface 1x DisplayPort, 1x HDMI, 1x LVDS, 1x eDP, 1x VGA
USB 2.0 4
USB 3.0 4
RS232 2
RS232/422/48585 N/A
WiFi option YES
SIM Slot YES
Power Consumption 19V
Temperature Range 0ºC ~ +60ºC
